How to arrange cable trays in a low-voltage electrical shaft

Cable trays in low-voltage shafts are installed by selecting the appropriate tray type, securing it with proper supports, maintaining code-compliant clearances, and organizing cables to prevent overheating and interference.

Planning and Tray Selection

Before installation, plan the cable routes carefully, considering the number and type of low-voltage cables, shaft dimensions, and future expansion needs ( ). Common tray types include ladder trays for larger bundles and better ventilation, and ventilated troughs for smaller, sensitive low-voltage cables ( ). Materials such as aluminum, steel, or FRP are chosen based on environmental conditions and load requirements ( ).

Support and Mounting

Cable trays must be mechanically supported at intervals specified by the manufacturer and NEC guidelines. In vertical shafts, use wall-mounted brackets, clevis hangers, or threaded rods to secure trays, ensuring they remain stable and aligned ( ). Supports should allow for thermal expansion and avoid excessive stress on cables.

Clearance and Accessibility

Maintain adequate vertical clearance above the tray for installation and maintenance, typically at least 12 inches ( ). Trays must remain accessible and should not be enclosed in a way that prevents inspection or cable replacement ( ). Avoid installing trays in hoistways or areas prone to physical damage.

Cable Installation and Organization

Use low-voltage cables rated for tray use, such as Tray Rated (Type TC) or Metal-Clad (Type MC) ( ). Separate high-power and low-voltage cables to prevent electromagnetic interference (EMI) ( ).

Follow NE

C fill limits: typically 40% for power cables and 50% for control or low-voltage cables ( ). Secure cables to the tray using cable ties or clamps, avoiding sharp bends and excessive tension ( ).

Grounding and Bonding

For metallic trays, ensure continuous grounding by bonding all sections and fittings with listed connectors or bonding jumpers. This provides a low-impedance path for fault currents and enhances safety ( ).

Safety and Compliance

Verify that all cables and trays comply with NEC Article 392 ( ). Consider covers if the shaft is high-traffic or exposed to potential mechanical damage ( ). Ensure proper fire-stopping where trays pass through walls or partitions to prevent fire spread ( ).

By following these steps—careful planning, proper tray selection, secure support, code-compliant clearances, organized cable routing, and grounding—low-voltage cable trays can be safely and efficiently installed in electrical shafts, allowing for future maintenance and expansion ( ).
