Cable tray changes from horizontal to vertical

Transitioning a cable tray from horizontal to vertical can be efficiently achieved using specialized fittings like the Helix™ or Vertical Up trays, which save space and simplify installation. Using Helix™ FittingsThe Helix™ cable tray fittings from Thomas & Betts are designed specifically for converting horizontal cable tray runs to vertical ones, particularly in confined areas or near walls. Key features include: Space efficiency: Requires significantly less room than traditional bends or elbows.

Pre-assembled options: Available in aluminum, pre-galvanized steel, and stainless steel, in 12-inch and 24-inch widths with 6-inch side rails, ready to install without on-site configuration. Left or right configurations: Allows flexibility depending on the installation layout. Cable protection: Secures cables within the fitting for organized and safe routing.

Time-saving: Reduces installation time by eliminating the need to reposition the tray for transitional fittings. These fittings are ideal for industrial, commercial, and utility applications, and BIM data is available for planning and design purposes.

Using Wire Basket Vertical Up Trays

For low-voltage cabling systems, the nVent CADDY Wire Basket Tray Vertical Up provides a solution for upward transitions from horizontal runs. Features include: Underfloor or wall applications: Supports vertical routing in tight spaces. Left and right orientation: Ensures proper alignment with existing horizontal trays.

Cable management: Maintains organized cable runs while transitioning vertically.

General Installation Tips

Plan the transition path: Ensure the vertical run does not interfere with other equipment or structural elements. Secure the tray: Use appropriate mounting hardware to support the vertical section and prevent sagging. Consider cable bend radius: Maintain manufacturer-recommended bend radius to avoid cable damage.

Check load capacity: Ensure the tray and fittings can support the weight of the cables in both horizontal and vertical sections. By selecting the appropriate transition fitting and following proper installation practices, horizontal-to-vertical cable tray conversions can be executed efficiently, safely, and with minimal space requirements.
