Metal sheath inside the optical cable

The metal sheath in optical cables primarily provides mechanical protection, moisture resistance, and environmental durability, ensuring the integrity and longevity of the optical fibers.

Mechanical Protection

A metal sheath acts as a robust armor around the optical cable core, shielding the delicate glass fibers from physical damage such as crushing, bending, or impact during installation and operation. This is especially important in harsh environments like underground, underwater, or industrial settings, where cables may be exposed to heavy loads, abrasion, or rodent attacks. The sheath can be made of steel or aluminum strips, often coated with plastic for additional protection.

Moisture and Environmental Resistance

Metal sheaths prevent water or moisture from entering the cable core, which could otherwise degrade the optical fibers and impair signal transmission. Some designs, like semi-hermetic bonded aluminum or steel sheaths, provide a barrier against humidity, chemical corrosion, and environmental contaminants. In addition, oil-filled or compound-filled cores can further prevent moisture spread if the sheath is breached.

Fire Resistance and Safety

In certain applications, metal sheaths enhance fire resistance. For example, mineral-insulated cables use a solid metal sheath with magnesium oxide insulation to maintain circuit integrity at temperatures exceeding 950°C, making them suitable for fire alarm systems and emergency power circuits. This ensures that optical communication or control systems remain operational during fire events.

Additional Benefits

Rodent and pest protection: Metal sheaths can prevent damage from animals in tunnels or underground installations. Durability in extreme conditions: They provide resistance to UV radiation, chemical exposure, and mechanical stress, extending cable lifespan. Structural support: In armored cables, the metal sheath can also serve as a grounding path or contribute to overall cable rigidity.

In summary, the metal sheath in optical cables is a critical component that protects the fibers from mechanical, environmental, and thermal hazards, ensuring reliable performance in demanding installation conditions. Its design and material selection depend on the specific application, such as direct burial, overhead, or industrial use.
